The Avantone Pro CLA-200 Studio Reference Amplifier is a classically designed Class A/B amplifier. We took particular care to create an amplifier in the traditional studio style, with generous VU meters, high quality Japanese components and a serious toroidal transformer linear power supply. In a standard 2U rack mount chassis, this amplifier can generate over 200 watts per channel into an 8 ohm load, making it perfect for medium to large speakers in a studio environment. The CLA200 is convection cooled – no fan noise, so it can be used in the same room as the monitors
Frequency Response: 20Hz-20kHz +/- 0.5dB
Output power:
200W at 8 ohms
300W at 4 ohms
500W bridged into 8 ohms
Distortion: <0.05%
Signal to Noise: >94dB
Input Impedance: (Balanced) 20KO (Unbalanced) 10kO
Damping Factor (100Hz, 8O): 250
Signal to Noise Ratio (A Weighted): >103dB
Amplifier: Class AB
Slew rate (at 1KHz): 28V/us
Input Sensitivity (1KHz): 0.775V (0dBU)
Total Harmonic Distortion (1KHz): <0.1%
Intermodulation distortion (at 10% rated power 1KHz): <0.1%
Crosstalk: -70dB
Cabinet Dimensions: 19”w x 18”d x 3.5”h 30.4 lbs
Weight: 20kg (44lb)
